Cooling Tower Valves
When you need a bleed/blowdown valve for a cooling tower application, Lakewood has just the answer – our line of Sprite Motorized Ball Valves is just right. These mini 2-way motorized ball valves have actuators in the shape of a cube less than 3″ on a side. The ball valves themselves are available in 1/2″, 3/4″, and 1-inch sizes, and can be purchased in CPVC, Brass, or 316 Stainless. These valves are proven in years of service and they resist fouling due to solids. No valve is impervious, but these are really good as well as inexpensive.
- CPVC: 1/2″ 1269072, 3/4″ 1269073, and 1″ 1269074
- Brass: 1/2″ 1269076, 3/4″ 1269077, and 1″ 1269078
- 316 SS: 1/2″1269080, 3/4″ 1269081, and 1″ 1269082
Boiler Blowdown Valves
Boilers are a whole different story, obviously! Lakewood carries excellent high pressure and temperature boiler blowdown valves that get the job
done. Rated to 400 psi @486F (27.58 bar at 252C), these valves use a 316 SS ball and Jamesbury XTREME seals. The only thing you need to consider is whether you need 1/2″ or 3/4″. Easy.
- MBV1 – 1/2″, 1268608
- MBV2 – 3/4″, 1268614
